Gear Ratio Parameter
Parameter | Stage3 | |
Transmission efficiency | 73% | |
Rated tolerance torque | 40N.m | |
Input and output direction | Reverse direction | |
Max momentary tolerance torque | Two times of the rated torque | |
Operating temperature | -10℃ ~ +80℃ | |
Operating ambient humidity | 20% 〜85%RH | |
Recommend input speed | ≤3000rpm | |
Motor matching scheme
Module | No.of teeth | Stage3 | |
5 | 30 | ||
10 | 50 | ||
15 | 100 | ||
20 | 200 | ||
