Stage1

3.7 ~ 5.2

25.7

Stage2

14 ~ 27

32.8

Stage3

51 ~ 139

39.7

Stage4

189 ~720

46.6

Transmission efficiency

90%

81%

73%

66%

Rated tolerance torque

0.3N.m

1.2N.m

2.5N.m

3.0N.m

Max momentary tolerance torque

 Three times of the rated torque

Operating temperature

-10℃~ +80℃

Operating ambient humidity

20% ~ 85%RH

Recommend input speed

≤4000rpm

Input and output direction

Same direction

0.5

17

3.7

14

51

189

11

5.2

19

71

265

27

100

369

139

516

720
