36JXE30K/36ZWNP40

Motor Technical DataTYPENumberof polesNumberof phaseRated voltage VDCNo-load&nbs...

Material of the internal gear ring
36JXE30K/36ZWNP40: Metal material
36JXF30K/36ZWNP40: Powdered metal
Diameter: Φ36mm planetary reducer
Allowable torque range: 0.3m to 3N.m
Brushless DC motor, 3-phase 4-pole, built-in driver

Online Contact

PDF Download

product details

Outline reference diagram

Motor Technical Data

TYPE

Number

of poles

Number

of phase

Rated

voltage

VDC

No-load

speed

r/min

No-load

current

mA

Rated

torque

mN.m

Rated

speed

r/min

Rated

current

mA

Rated

Power

W

36ZWNP40-1240

4

3

12

4000

400

15

3000

850

4.7

36ZWNP40-2440

4

3

24

4000

200

20

3000

550

6.3

Brushless Gear Motor Technical Data

36ZWNP40-1240 BLDC Motor

Reduction ratio	3.7	5.2	14	19	27	51	71	100	139	189	264	369
Number of gear trains	1	1	2	2	2	3	3	3	3	4	4	4
Length(L) mm	26.5	26.5	33.6	33.6	33.6	40.5	40.5	40.5	40.5	47.4	47.4	47.4
No-load speed r/min	1078	772	286	211	148	78	56	40	29	21	15	11
Rated speed rAnin	809	579	214	158	111	59	42	30	22	16	11	8.1
Rated torque N.m	0.05	0.07	0.17	0.23	0.33	0.56	0.78	1.1	1.5	1.8	2.6	3
N.m Max. permissible load in a short time	1.0	1.0	3.5	3.5	3.5	7.5	7.5	7.5	7.5	9	9	9

36ZWNP40-2440 BLDC Motor

Reduction ratio	3.7	5.2	14	19	27	51	71	100	139	189	264	369
Number of gear trains	1	1	2	2	2	3	3	3	3	4	4	4
Length(L) mm	26.5	26.5	33.6	33.6	33.6	40.5	40.5	40.5	40.5	47.4	47.4	47.4
No-load speed r/min	1078	772	286	211	148	78	56	40	29	21	15	11
Rated speed rAnin	809	579	214	158	111	59	42	30	22	16	11	8.1
Rated torque N.m	0.067	0.093	0.23	0.31	0.44	0.74	1.0	1.5	2.0	2.5	3	3
N.m Max. permissible load in a short time	1.0	1.0	3.5	3.5	3.5	7.5	7.5	7.5	7.5	9	9	9
