Description of The Product
45MM OD PMDC motor, totally enclosed, used in occasions which require motors with low noise.
Motor Technical Data
Type | Rated Voltage DVC | No-load speed r/min | No-load current A | Rated speed r/min | Rated Torque mN.m | Output power W | Rated current A | Stall Torque mN.m | Stall Current A |
45ZY78-2430 | 24 | 3000 | 0.22 | 2400 | 55 | 15 | 1.0 | 240 | 3.0 |
45ZY78-2440 | 24 | 4000 | 0.30 | 3200 | 70 | 23 | 1.5 | 310 | 4.8 |
