•  Description of The Product

52MM OD PMDC motor, totally enclosed, used in occasions which require motors with low noise

• Motor Technical Data

  TYPE	Rated  voltage  VDC	No-load speed r/min	No-load  current A	Rated  Speed  r/min	Rated  torque  mN.m	Output  Power W	Rated  current A	Stall  torque  mN.m	Stall  Current A
  52ZY125-2420	24	2000	0.40	1600	160	30	2.0	620	6.5
  52ZY125-2430	24	3000	0.60	2400	190	50	3.5	700	11.5
  52ZY125-2440	24	4000	0.80	3200	220	80	4.5	838	16.4
