Stage2

3.6 ~ 18

32

Stage3

20 ~ 50

40

Stage4

60 ~ 200

Transmission efficiency

81%

73%

66%

Rated tolerance torque

1N.m

2N.m

5N.m

Input and output direction

Same direction

Reverse direction

Same direction

Max momentary tolerance torque

 Two times of the rated torque

Operating temperature

-10℃~ +80℃

Operating ambient humidity

20% ~ 85%RH

Recommend input speed

≤3000rpm

0.5

8

3.6

20

60

5

25

75

6

30

90

7.5

36

100

8.4

40

120

9

44

150

10

47

180

12.5

50

200

15

18
