• Description of The Product

45MM OD rare earth PMDC motor, totally enclosed, used in occasions which require motors with low noise.

• Motor Technical Data

  TYPE	Rated  voltage VDC	No-load  speed r/min	No-load  current A	Rated  speed  r/min	Rated  torque  mN.m	Output  Power W	Rated  current A	Stall  torque  mN.m	Stall  current A
  45ZYN78-2420	24	2000	0.25	1600	80	13	0.8	310	3.0
  45ZYN78-2425	24	2500	0.30	2000	130	25	1.7	570	6.6
  45ZYN78-2430	24	3000	0.30	2400	150	30	2.5	720	7.5
