Description of The Product
60MM OD PMDC motor, totally enclosed, used in occasions which require motors with low noise.
Motor Technical Data
TYPE | Rated voltage VDC | No-load speed r/min | No-load current A | Rated Speed r/min | Rated torque mN.m | Output Power W | Rated current A | Stall torque mN.m | Stall Current A |
60ZY75-2420 | 24 | 2000 | 0.3 | 1600 | 50 | 8 | 0.8 | 215 | 2.1 |
60ZY75-2430 | 24 | 3000 | 0.4 | 2400 | 70 | 17 | 1.2 | 296 | 5.0 |
60ZY75-2440 | 24 | 4000 | 0.5 | 3200 | 90 | 30 | 2.2 | 404 | 8.5 |
