• Description of The Product

96MM OD PMDC motor, totally enclosed, used in occasions which require motors with low noise.

• Motor Technical Data




  TYPE	Rated  voltage  VDC	No-load  speed  r/min	No-load  current A	Rated Speed  r/min	Rated  Torque  N.m	Output  power W	Rated  current A	Stall  Torque  N.m	Stall  Current A
  96ZY140-2420	24	2000	1.0	1600	0.80	150	9.0	4.0	40
  96ZY140-2435	24	3500	1.8	2800	0.95	200	13	5.5	50
