Description of The Product
80MM OD PMDC motor, totally enclosed, used in occasions which require motors with low noise.
Motor Technical Data
TYPE | Rated voltage VDC | No-load speed r/min | No-load current A | Rated Speed r/min | Rated Torque N.m | Output power W | Rated current A | Stall Torque N.m | Stall Current A |
80ZY125-2420 | 24 | 2000 | 0.5 | 1700 | 0.64 | 110 | 6 | 2.9 | 27 |
80ZY125-2435 | 24 | 3500 | 1.2 | 3000 | 0.70 | 200 | 10 | 3.2 | 45 |
