Permanent magnet DC worm gear reduction motor
-
63JW/63ZY125
Description of The Product
1、Suitable application: gearbox and motor output shafts form a right angle.
2、12VDC is available, motor speed is adjustable upon request.
3、Encoder & brake is available upon request.
Motor Technical Data
Type | Rated voltage VDC | No-load speed r/min | No-load current A | Rated speed r/min | Rated Torque mN.m | Output power W | Rated current A | Stall torque mN.m | Stall Current A |
63ZY125-2430 | 24 | 3000 | 0.5 | 2600 | 0.25 | 70 | 4.6 | 1.1 | 20 |
63ZY125-3633 | 36 | 3300 | 0.5 | 2700 | 0.34 | 100 | 4.0 | 1.6 | 16 |
Gear Motor Technical Data
63ZY125-2430 DC Motor
Reduction ratio | 30 | 15 | 10 |
Number of gear trains | 1 | 2 | 3 |
No-load speed r/min | 100 | 200 | 300 |
Rated speed r/min | 87 | 173 | 260 |
Rated torque N.m | 5.2 | 3.0 | 2.1 |
N.m Max. permissible load in a short time | 8.0 | 5.0 | 5.0 |
63ZY125-3633 DC Motor
Reduction ratio | 30 | 15 | 10 |
Number of gear trains | 1 | 2 | 3 |
No-load speed r/min | 110 | 220 | 330 |
Rated speed r/min | 90 | 180 | 270 |
Rated torque N.m | 7.1 | 4.0 | 2.9 |
N.m Max. permissible load in a short time | 8.0 | 5.0 | 5.0 |
