产品特点和用途 Description of The Product
1、全部滚动轴承的配置，可以提供左出轴、右出轴、空心出轴。
2、客户可以在空心出轴内自行配置各种长度、形状、方向的输出轴。
1、All equipped with ball bearings, left, right or hollow output shaft are available.
2、Customers can equip output shafts of different length, shape or directions within hollow shaft.
电动机主要技术参数 Motor Technical Data
电机型号 Type | 额定电压 Rated voltage VDC | 空载转速 No-load speed r/min | 空载电流 No-load current A | 额定转速 Rated speed r/min | 额定转矩 Rated Torque mN.m | 输出功率 Output power W | 额定电流 Rated current A | 堵转转矩 Stall torque mN.m | 堵转电流 Stall Current A |
83ZY125-2420 | 24 | 2000 | 0.8 | 1700 | 0.24 | 42 | 3.5 | 1.6 | 17 |
83ZY125-2430 | 24 | 3000 | 0.9 | 2500 | 0.30 | 77 | 4.6 | 1.8 | 20 |
齿轮减速电机主要技术参数 Gear Motor Technical Data
配置 83ZY125-2420 直流电机(83ZY125-2420 DC Motor)
减 速 比 Reduction ratio | 50 | 40 | 32 | 25 | 16 | 12.5 |
减速级数 Number of gear trains | 1 | 1 | 1 | 1 | 2 | 2 |
空载转速 No-load speed r/min | 40 | 50 | 62 | 80 | 125 | 160 |
额定转速 Rated speed r/min | 30 | 37 | 46 | 60 | 93 | 120 |
额定转矩 Rated torque N.m | 8.4 | 6.7 | 5.3 | 4.2 | 3.0 | 2.4 |
最大瞬间允许负载 N.m Max. permissible load in a short time | 20 | 20 | 20 | 20 | 10 | 10 |
配置 83ZY125-2430 直流电机(83ZY125-2430 DC Motor)
减 速 比 Reduction ratio | 50 | 40 | 32 | 25 | 16 | 12.5 |
减速级数 Number of gear trains | 1 | 1 | 1 | 1 | 2 | 2 |
空载转速 No-load speed r/min | 60 | 75 | 93 | 120 | 187 | 240 |
额定转速 Rated speed r/min | 46 | 57 | 71 | 92 | 143 | 184 |
额定转矩 Rated torque N.m | 10.5 | 8.4 | 6.7 | 5.2 | 3.8 | 3.0 |
最大瞬间允许负载 N.m Max. permissible load in a short time | 20 | 20 | 20 | 20 | 10 | 10 |
